Description

Ventilator setting

Ventilation mode: VCV, PCV, PSV, SIMV-V, SIMV-P, SPONT, CPAP, backup apnea ventilation, APRV, BIPAP (optional)

Tidal volume: 50~1500ml

Breath rate: 1~100bpm

SIMV breath rate: 1~40bpm

Inspiratory time: 0.1~12s

Pause time: 0~4.8s

Pressure trgger sensitivity: (PEEP-20cmH2O)~PEEPcmH2O

Flow trigger sensitivity: 1~20LPM

PSV: 0~70cmH2O

High pressure: 1~80cmH2O

Low pressure: 0~79cmH2O

Waveforms displayed: P-T, F-T, V-T, P-V loop, V-F loop

PEEP/CPAP: 0~50cmH2O

FiO2: 21~100%

Psupp: 0~70cmH2O

Pinsp: 5~70cmH2O

Thigh: 0.1~30s

Tlow: 0.5~30s

Phigh: 5~70cmH2O

Plow: 0~50cmH2O

Alarm silence: ≤120s

Parameters monitored: VTI, VTE, MV, MVspn, f, fspn, FiO2, Ppeak, Pmean, Pplat, PEEP, Pmin, Compliance, Resistance

Interface: RS232, VGA
